Eva400Eva400Eva400 Videos All videos Eva400 Strong, safe and easy to manoeuvre Eva400 is a versatile mobile patient lift for all lifting situations and for users weighing up to 180 kg/400 lbs. When used with Handicare’s functional and easy-to-use lifting accessories, Eva400 is the right choice for lifting in connection with transfers to and from the floor, chair or bed, as well as for horizontal lifting and gait training. Two variants with different base-width adjustment Eva400 is available in two variants; with electrical (EE) or manual (EM) base-width adjustment. Both variants of Eva400 are supplied complete and ready to use, fitted with a stable sling bar with reliable safety latches and a hand control. The sling bar is standard width (450 mm/17.7″) which is suitable for most users and lifting situations. Strong and stable, SWL 180 kg/400 lbs Aluminium for low weight – easy to manoeuvre Mast adjustable to three height positions – large lifting range Height-adjustable handle bars – comfortable and ergonomic working positions Stable aluminium sling bar with reliable safety latches Standard width sling bar – suitable for most users and situations Encapsulated twin castors – easy rolling and maintenance-free Available with electrical or manual base widening Electrical emergency stop button readily available on the control box Electrical and manual emergency lowering High capacity battery with long service life External charger – only low voltage (24V) to the lift Quick guide on the lift Many accessories for safe, easy and individually adapted lifting of users Both variants of Eva400 comply with requirements of the Medical Devices Directive for Class 1 products (MDD93/42/EEC). Handicare lifting slings and other accessories To create optimal solutions for users with different needs, Eva400 can be used in combination with lifting slings and many clever and functional lifting accessories in Handicare’s Lifting range. AmbulationArm, for example, is an accessory which can be employed as armrests by the user during gait training but they can also be used by the caregiver for manoeuvring the lift. Click “Accessories” hereunder for more information. Send a messageName*Email* Country*MessageEmailThis field is for validation purposes and should be left unchanged.
Application areas Model specification Documents Application areas Turning In Bed From Bed To Commode Up From The Floor From Bed To Wheelchair From Wheelchair To Toilet Higher Up In Bed Lying To Sitting Positioning In Chair Rising To Sitting Down Standing Training Supine Transfer Support For Gait Training Model specificationArt. no.6010000160100011NameEva400Eva400DescriptionMobile lift with electrical base widening, complete with sling bar and hand controlMobile lift with manual base widening, complete with sling bar and hand controlBase width, outer dimensions685-980 mm685-980 mmBase width, inner dimensions585-880 mm585-880 mmTotal weight34 kg34 kgLifting range530-1790 mm530-1790 mmLifting speed without load23 mm/s23 mm/sBattery capacity2.9 Ah2.9 AhSling bar width450 mm450 mmProtection classIPX4IPX4SWL180 kg180 kgCastors, diameter100 mm100 mmUnit11MaterialAluminiumAluminiumBase wideningElectricalManualEmergency loweringManual and electricalManual and electricalMaterial, sling barAluminiumAluminium DocumentsDocument nameTypeSize User Manual Eva (multilingual) 10 MB Care instructions (multilingual) 2 MB Re-conditioning EVA HC EN 157 KB Safety information (multilingual) 2 MB Rekonditionering Eva400 SE 158 KB Technical data sheet Eva400EE 888 KB
