Strong, safe and easy to manoeuvre

Application areas
  • Positioning In Chair
  • Rising To Sitting Down
  • Standing Training
  • Supine Transfer
  • Support For Gait Training
  • Turning In Bed
  • From Bed To Commode
  • Up From The Floor
  • From Bed To Wheelchair
  • From Wheelchair To Toilet
  • Higher Up In Bed
  • Lying To Sitting
Model specification
Art. no.6010000160100011
DescriptionMobile lift with electrical base widening, complete with sling bar and hand controlMobile lift with manual base widening, complete with sling bar and hand control
Base width, outer dimensions685-980 mm685-980 mm
Base width, inner dimensions585-880 mm585-880 mm
Total weight34 kg34 kg
Lifting range530-1790 mm530-1790 mm
Lifting speed without load23 mm/s23 mm/s
Battery capacity2.9 Ah2.9 Ah
Sling bar width450 mm450 mm
Protection classIPX4 IPX4
Safe working load180 kg180 kg
Castors, diameter100 mm100 mm
Unit1 1
Base wideningElectricalManual
Emergency loweringManual and electricalManual and electrical
Material, sling barAluminiumAluminium
