Extra strong and safe, for heavier users

Application areas
  • Positioning In Chair
  • Rising To Sitting Down
  • Standing Training
  • Supine Transfer
  • Support For Gait Training
  • Turning In Bed
  • From Bed To Commode
  • Up From The Floor
  • From Bed To Wheelchair
  • From Wheelchair To Toilet
  • Higher Up In Bed
  • Lying To Sitting
Model specification
Art. no.6010000360100010
DescriptionMobile lift with electrical base widening, complete with sling bar and hand controlMobile lift with electrical base widening, with low legs, complete with sling bar and hand control
Base width, outer dimensions750-1150 mm750-1150 mm
Base width, inner dimensions650-1050 mm650-1050 mm
Total weight39 kg39 kg
Lifting range500-1810 mm500-1810 mm
Lifting speed without load35 mm/s35 mm/s
Battery capacity2.9 Ah2.9 Ah
Sling bar width600 mm600 mm
Protection classIPX4 IPX4
Safe working load270 kg270 kg
Unit1 1
Front castors, diameter100 mm35 mm
Rear castors, diameter100 mm100 mm
Base wideningElectricalElectrical
Emergency loweringManual and electricalManual and electrical
Material, sling barAluminiumAluminium
